SMARTAGRO CROSS
SMARTAGRO CROSS
“Feel where traction goes hand in hand with comfort.”
- Up to 40% more load capacity.
- SmartFlexible sidewall for larger footprint and lower soil compaction.
- Reinforced puncture resistance.
- Strong casing and increased pair of lugs,ensures outstanding durability along with strong stability.
Tires are the essential point of contact between your machine and the field. We work to ensure that your tires will always offer excellent stubble resistance, endurance, and pure driving pleasure.
Technical detalis
Hi FLEX TECHNOLOGY
Uniglory Hi Flex Technologies turn over greater casing flexibility, resulting in increased durability, a larger footprint and reduced soil compaction.
- The reinforced breaker & carcass layer enhance the pucture resistance and optimized load capacity of the Hi Flex technology tires .
- The upgrade bead especially designed for Hi Flex technology tires, improve the sidewall flexibility.
- The Hi Flex Technology provides a outstanding enhancement in sidewall flection.
Hi Flex Technology tires can carry +20% loads (IF Tires) with the same air pressure or same loads at 20% lower air pressure, +40% loads with the same air pressure or same loads at 40% lower air pressure for a Very HIgh Flexion tires(VF Tires) .
| Size(Metric) | Size(Inch) | Service Desc. | T.D(mm) | S.W(mm) | O.D(mm) | R.C(mm) | Recommended Rim | Acceptable Rim |
|---|---|---|---|---|---|---|---|---|
| VF320/90R42 | 12.4R42 | 168D | 42 | 330 | 1645 | 5031 | W 10 | W 11 W 9 |
| VF320/90R54 | 12.4R54 | 168D | 42 | 330 | 1958 | 6012 | W 11 | W 9 W 10 |
| VF340/85R38 | 13.6R38 | 164D | 38 | 350 | 1552 | 4738 | — | — |
| VF380/85R34 | 14.9R34 | 151D | 46 | 380 | 1510 | 4475 | — | — |
| VF380/90R46 | 14.9R46 | 173D | 38 | 385 | 1852 | 5656 | DW 13 | DW 12 |
| VF380/95R38 | — | 169D | 47 | 380 | 1703 | 5046 | — | — |
| VF380/105R50 | — | 181D | 46 | 400 | 2050 | 6210 | — | — |
| VF380/105R54 | — | 185D | 48 | 400 | 2150 | 6434 | — | — |
| VF420/80R46 | — | 179D | 46 | 425 | 1860 | 5577 | — | — |
| VF420/85R34 | 16.9R34 | 159D | 48 | 430 | 1584 | 4683 | — | — |
| VF480/70R46 | — | 176D | 48 | 485 | 1868 | 5630 | — | — |
| VF480/70R54 | — | 185D | 49 | 488 | 2055 | 6294 | W 16 A | — |
| VF480/80R46 | 18.4R46 | 177D | 42 | 480 | 1936 | 5900 | DW 16 L | DW 15 L DW 18 L |
| VF480/80R50 | 18.4R50 | 179D | 42 | 485 | 2038 | 6220 | W 16 | W 15 W 14 |
| VF480/95R50 | — | 179D | 51 | 485 | 2189 | 6468 | — | — |
| VF620/70R46 | — | 179D | 52 | 630 | 2036 | 6190 | W 18 L | DW 18 L DW 20 B MW 20 B |
| VF620/70R46 | — | 185D | 52 | 630 | 2036 | 6190 | — | — |
| VF680/50R46 | — | 174D | 52 | 690 | 1860 | 5575 | — | — |
